NMB PM42L-048-FEC2 Motor

Motor SizePM42L-048

Number of Steps per Rotation48 (7.5deg/Step)

Drive Method2-2 PHASE

Drive CircuitUNIPOLAR CONST. VOLT.BIPOLAR CHOPPER

Drive Voltage24[V]24[V]

Current/Phase　600[mA]

Coil Resistance/Phase60[ohms]7[ohms]

Drive IC2SC3346UDN2916B-V

Magnet MaterialFerrite plastic magnet(MSPL)

Polar anisotropy ferrite sintered magnet(MS50)

Nd-Fe-B bonded magnet(MS70)

Insulation Resistance100M[ohms]MIN

Dielectric StrengthAC 500[V]1[min]

Class of InsulationCLASS E

Operating Temp.-10[deg.C] - 50[deg.C]

Storage Temp.-30[deg.C] - 80[deg.C]

Operating Hum.20[%]RH - 90[%]RH
